MIL-DTL-12560K (MR)
APPENDIX A
L1
Stamped Plate
Identification
L1 ± 0.5"
2
a
+
6"
L2 ± 0.5"
a = 3" -0.000"
3"
2
+0.500"
+
a
L2
Not to Scale
FIGURE A-1. Lifting holes for ballistic acceptance test plates
2.751 through 6.25 inches thick.
51
